Thermionics Model Number
|
Description
|
| 016019 |
Thermionics’ PyraFlat™ metal sealed flange. 1.046″ x 0.722″ ID |
| 021033 |
Thermionics’ PyraFlat™ metal sealed flange. 2.188″ x 0.756″ ID. |
| 026046 |
Thermionics’ PyraFlat™ metal sealed flange. 3.125″ x 1.125″ ID. |
| 026056 |
Thermionics’ PyraFlat™ metal sealed flange. 4.125″ x 1.125″ ID. |
| 035073 |
Thermionics’ PyraFlat™ metal sealed flange. 5.25″ x 1.50″ ID. |
| 035098 |
Thermionics’ PyraFlat™ metal sealed flange. 7.750″ x 1.500″ ID. |
| 033115 |
Thermionics’ PyraFlat™ metal sealed flange. 9.730″ x 1.520″ ID. |
| 043124 |
Thermionics’ PyraFlat™ metal sealed flange. 10.125″ x 2.00″ ID. |
| 042145 |
Thermionics’ PyraFlat™ metal sealed flange. 12.250″ x 1.900″ ID. |
| 029029 |
Thermionics’ PyraFlat™ metal sealed flange. 1.370″X1.370″ ID. |
| 034034 |
Thermionics’ PyraFlat™ metal sealed flange. 1.870″ x 1.870″ ID. |
| 044044 |
Thermionics’ PyraFlat™ metal sealed flange. 2.370″ x 2.370″ ID. |
| 049049 |
Thermionics’ PyraFlat™ metal sealed flange. 2.870″ x 2.870″ ID. |
| 059059 |
Thermionics’ PyraFlat™ metal sealed flange. 3.834″ x 3.834″ ID. |
| 069069 |
Thermionics’ PyraFlat™ metal sealed flange. 4.834″ x 4.834″ ID. |
| 079079 |
Thermionics’ PyraFlat™ metal sealed flange. 5.834″ x 5.834″ ID. |
| 099099 |
Thermionics’ PyraFlat™ metal sealed flange. 7.834″ x 7.834″ ID. |
| 127127 |
Thermionics’ PyraFlat™ metal sealed flange. 9.760″ x 9.760″ ID. |
| 147147 |
Thermionics’ PyraFlat™ metal sealed flange. 11.76″ x 11.76″ ID. |
| 167167 |
Thermionics’ PyraFlat™ metal sealed flange. 13.76″ x 13.76″ ID. |
| *Add suffixes as follows: T=Tapped Flange, B=Blank Flange (no extra charge), BT=Blank Tapped Flange |
| Larger or other sizes and shapes available on request. |
